In this blog I will explain the logic used to create unique Wangdenticons for a given text.

This whole thing started not so long ago when I was learning Elixir from Udemy. The instructor was explaining how Identicon works and how it is generated. The basic idea of an Identicon is to hash a given text using any cryptographic hash function (for uniqueness), and use that hash value to generate image following a certain pre-defined rules.

It can be be any algorithm of your choice, e.g.- take first 3 values in hexadecimal representation of the hash value for the color, or take last 3 values for the color and use the other values to generate a specefic pixel based on the value, etc.

In my case I mixed Identicon and Wangtiles to create Wangdenticon (github source code).

Following is the rule I used to generate Wangenticon based on given text.

High level description of Algorithm

First, the text is hashed using md5 hash function to generate 128-bit hash value. The hash value is stored as an array of length 16, each position containing an 8-bit value.

Code language not defined !

-- TODO: Image here illustrating above process

First 3-bytes are used to decide the foreground color.

Code language not defined !

-- TODO: Image here illustrating above process

For a given gridsize, a 2d-array of (gridsize * gridsize) is created. This array will be filled with a wangtiles based on the following algorithm, to produce the final image.

We first calculate an offset,

Code language not defined !

Then, we iterate over all the indexes (y, x) (for only vertically left-half portion of the 2d-array, because the image has to be symmetric, for a given left tile we can generate the corresponding opposite right tile (in code using OPPOSITE_MAP)). For each index (y, x) we calculate a position in hex_list using

Code language not defined !

Then we fill in the left & right positions of the image generated using the above number: tile and an tile generating algorithm wang_tile (described below).

If (y, x) is any index in the middle column of the image (in case of odd gridsize), a predefined middle_tile is used to fill that position instead. This middle_tile is based on the last value of hex_list array.

Code language not defined !

Tile Generating Algorithm

Now let's look at the tile generating algorithm-

For a given integer n, we calculate a value m between 0 to 15 using-

Code language not defined !

A tile is a 3x3 grid containing pixel values. These will be either fgcolor, or a given bgcolor

Since, m is between 0 to 15, it can be represented as a 4-bit number. We will be using these bits to decide which side of the tile has to be filled with fgcolor or bgcolor
